| Products => Terminal => 187 Series => 187 Series straight receptacles |
| กก |
|
|
|
|
| Part No | Applicable wire |
Fit Tab Thickness (mm) |
Material | Finish | Qty / Reel | Approval | |
| AWG | mm2 | ||||||
| RE1870501-36 | 22-18 | 0.3-0.8 | 0.5 | Brass | Natural | 8000 | E116143 |
| RE1870502-36 | 22-18 | 0.3-0.8 | 0.5 | Brass | Tinned | 8000 | E116143 |
| RE1870503-36 | 22-18 | 0.3-0.8 | 0.5 | Steel | Nickel | 8000 | ---- |
| RE1870504-36 | 22-18 | 0.3-0.8 | 0.5 | Brass | Nickel | 8000 | E116143 |
| RE1870801-36 | 22-18 | 0.3-0.8 | 0.8 | Brass | Natural | 8000 | E116143 |
| RE1870802-36 | 22-18 | 0.3-0.8 | 0.8 | Brass | Tinned | 8000 | E116143 |
| RE1870803-36 | 22-18 | 0.3-0.8 | 0.8 | Steel | Nickel | 8000 | ---- |
| RE1870804-36 | 22-18 | 0.3-0.8 | 0.8 | Brass | Nickel | 8000 | E116143 |
Note :
1. Receptacles denoted by (2) is used only for two wires, If using wires in other combinations than the ones shown above, please contact Utilux South China Ltd.
2. Combine a plated straight receptacle with a plated tab and a non-plated receptacle with a non-plated tab.
