| Products => Terminal => RI850xxxx ring terminal Series |
|
|
 |
|
| Part No | Applicable wire | Diameter (mm) | Material | Finish | Qty / Reel | Approval | ||
| AWG | mm2 | OD | ID | |||||
| RI8503201-50 | 20-14 | 0.5-2.1 | 8.5 | 3.2 | Brass | Natural | 5000 | ---- |
| RI8503202-50 | 20-14 | 0.5-2.1 | 8.5 | 3.2 | Brass | Tinned | 5000 | ---- |
| RI8504301-50 | 20-14 | 0.5-2.1 | 8.5 | 4.3 | Brass | Natural | 5000 | ---- |
| RI8504302-50 | 20-14 | 0.5-2.1 | 8.5 | 4.3 | Brass | Tinned | 5000 | ---- |
| RI8505301-50 | 20-14 | 0.5-2.1 | 8.5 | 5.3 | Brass | Natural | 5000 | ---- |
| RI8505302-50 | 20-14 | 0.5-2.1 | 8.5 | 5.3 | Brass | Tinned | 5000 | ---- |
| RI8506202-50 | 20-14 | 0.5-2.1 | 8.5 | 6.2 | Brass | Tinned | 5000 | ---- |
| RI8506203-50 | 20-14 | 0.5-2.1 | 8.5 | 6.2 | Steel | Nickel | 5000 | ---- |
Note :
1. Receptacles denoted by (2) is used only for two wires, If using wires in other combinations than the ones shown above, please contact Utilux South China Ltd.
2. Combine a plated straight receptacle with a plated tab and a non-plated receptacle with a non-plated tab.
